ELM621LA
High efficiency 30V step up DC/DC converter
ELM621LA is a high efficiency step-up DC/DC converter using a constant frequency, current mode architecture.
Featuring current-mode and fixed frequency operation, this device incorporates an integrated main switch and the switching frequency is internally set at 1.3MHz,
allowing the use of small surface mount inductors and capacitor. As for the output voltage, it can be regulated ranging from 2.7V to 30V.
ELM621LA is available in a low profile TSOT-25 package.
| Current mode control | |
|---|
| Thermal shutdown protection | |
|---|
| Undervoltage-lockout (UVLO) | |
|---|
| Input voltage range | 2.5V to 5.5V |
|---|
| Internal current limit | 1.45A |
|---|
| Shutdown current | <0.1µA |
|---|
| Constant frequency operation | Typ.1.3MHz |
|---|
| High efficiency | 90% |
|---|
| Package | TSOT-25 |
|---|
| Datasheet | ELM621LA |
|---|
- Application
- Cellular telephones
- PDAs and smart phones
- MP3 player
- Wireless and DSL card
- Digital still cameras
- Slim-type DVD
- Portable instruments
